Newton 403 Hydrobond – External Waterproofing Membrane

High performance external membrane to provide a Type A (barrier) waterproofing solution. It achieves a full mechanical bond to concrete that stops water migration between the membrane and the structure. It provides protection against water ingress, the alkalinity of concrete and acts as a barrier to gases.

READ MORE...

Availability: In stock

You're logged into: TRADEZONE

RRP £440.00 Excl. VAT
£341.50 Excl. VAT £409.80 Incl. VAT
Description

HydroBond External Waterproofing Membrane

Newton 403 HydroBond is a high performance external waterproofing membrane. It provides a Type A (barrier) waterproofing solution to below ground and earth-retained structures.

How the HydroBond Membranes Works

One side of the membrane features a locking fleece and the other a polymer hydrophilic.

The fibres of the locking fleece allow the membrane to form a full mechanical bond with the concrete. This stops water tracking between the membrane and the structure when placed below the new raft or against permanent or temporary timber wall formwork.

The hydrophilic coating expands when it comes in contact with water. This allows it to seal small holes that may be formed during construction. This self-healing property deals with accidental punctures, providing peace of mind.

Newton 403 HydroBond can be used with other Newton products in order to waterproof a whole structure. Once correctly installed, it provides complete protection for the life of the building against water ingress. This includes the deck, through construction joints, through and around service entries and to movement joints.

Applications of HydroBond

The HydroBond is suitable for all below ground and earth-retained structures. It is ideal for every job from domestic basements up to large civil engineering projects.

HydroBond 403 can be used as a continuous membrane on permanent raft and wall formwork. This includes raft blinding and piled walls of reinforced concrete earth-retained structures.

It is suitable as raft or slab for the following substrates:

  • Concrete blinding
  • Compacted type 1 hardcore
  • Compacted sand

If you have any questions about Type A waterproofing solutions, concrete membranes or HydroBond specifically then please contact our expert team. You can also read more about installation in our external waterproofing guide.

Features

  • BDA Agrément Certified
  • NHBC accredited as a suitable Type A waterproofing system, for Grades 1, 2 and 3 as per BS 8102:2009
  • Provides a durable waterproof covering for the building’s lifetime (at least 60 years)
  • Excellent resistance to the high alkalinity of concrete
  • Self-healing quality when punctured due to the hydrophilic layer
  • Highly flexible making the membrane resistant to movement and fissures in the substrate
  • Certified as a barrier for radon, carbon dioxide and hydrocarbon gases

Please watch the below video for more information:



Features:

  • BDA Agrément Certified
  • NHBC accredited as a suitable Type A waterproofing system, for Grades 1, 2 and 3 as per BS 8102:2009
  • Provides a durable waterproof covering for the building’s lifetime (at least 60 years)
  • Excellent resistance to the high alkalinity of concrete
  • Self-healing quality when punctured due to the hydrophilic layer
  • Highly flexible making the membrane resistant to movement and fissures in the substrate
  • Certified as a barrier for radon, carbon dioxide and hydrocarbon gases
Specification
Specification
Model: JN403HB
SKU JN403HB
Manufacturer: Newton Waterproofing
Packaging: Individual Roll
Size: 1m x 20m roll
Dilution: N/A
Coverage: Up to 20m sq
Country of Manufacture: United Kingdom
Reviews

Be the first to review this product

How do you rate this product?


1 1 star
2 2 star
3 3 star
4 4 star
5 5 star
Price
Value
Quality
FAQs

Can Newton 403 Hydrobond be used internally?

No, Newton 403 Hydrobond is designed to be applied to the outside of the structure or under the slabbefore the slab is poured.

Is Newton 403 Hydrobond self adhesive?

Newton 403 is not self adhesive, it is designed to bond to poured concrete when it is poured over or against it wet. The concrete dries and bonds to the fleece side of the Hydrobond.
